CSE NN 7A PUR

New
DATA / ETHERNET CAT 7A S/FTP - AWG 26/7 - PUR

Our CSE NN 7A PUR data patch cable features our CCAT 7A PUR bulk cable and HIROSE® RJ45 connectors equipped with NEUTRIK® etherCON® cable connector protection. The CCAT 7A PUR network cable is the ideal choice for high-performance networks. Due to its double S/FTP shielding, it can transmit CAT 7A data class signals with an impressive bandwidth of 1000 MHz (1 GHz, Gigabit Ethernet). The robust PUR jacket effectively protects the cable from environmental influences and mechanical stress in the case of mobile indoor and outdoor applications.

It has specifically been developed for audio networks, lighting control and EtherSound™ systems and features a flexible inner conductor (AWG 26/7) thus making it ideal for patch cables and device connections.

Furthermore, it supports Power over Ethernet (PoE++) (complying with the IEEE 802.3af-2003 standard) with an output of 15.4 watts, enhancing its range of applications considerably.

Its high abrasion resistance and its resistance to oil, microbes and chemicals should also be emphasized. Whether for mobile applications, stage use or outdoor transmissions - this cable ensures superb performance and reliability, even under demanding conditions.

  • Flexible, robust, reelable
  • PUR jacket for mobile indoor/outdoor applications
  • Data class CAT 7A (1000 MHz)
  • Overall shield S/FTP
  • AWG 26/7, with 7 strands/conductors
  • PoE (15.4W)  complying with IEEE 802.3af-2003 standards,  max. channel PoE (15.4W) 70m
  • flame-retardant according to UL 1581 §1090, §1100 (FT2) and IEC 60332-1-2
  • halogen-free according to EN 50267-2-1 and IEC 60754-1
  • oil-resistant according to IEC 60811-2-1, ICEA S-82-552 and ASTM IRM 902
  • Sludge resistance according to NEK 606
  • Ozone resistance according to EN 50396
  • Microbe resistance according to VDE 0282/10
  • Chemical compatibility - good (diesel, kerosene, petroleum)
  • HIROSE® RJ45 connectors featuring the NEUTRIK® etherCON® cable connector protection.
  • Transparent shrink-on tube for easy cable identification

Applications: Data, Ethernet, audio networks, lighting control, EtherSound™

Product information
Bulk cable
Jacket PUR
cable assign RJ45 Pinout T568B
connector brand NEUTRIK ® / HIROSE ®
plugs
1x NEUTRIK® NE 8 MX-B-1 + HIROSE® RJ45 TM31
1x NEUTRIK® NE 8 MX-B-1 + HIROSE® RJ45 TM31
technical data
Technical facts
Connector recommendation see datasheet
Conductor area 0.14 mm²
AWG 26/7
Composition of conductor 7 x 0,14 mm²
Material PUR
Conductor isolation Foam-Skin PE nom. 1,05 mm
Shielding S/FTP
Overall Jacket PUR
Category Data / Ethernet
Overall diameter 6.4mm +/- 0.2mm
Weight bulk cable ca. 46kg/km
Capacity cond.-cond. (pF/m) nom < 44 pF/m
Conductor resistance 140 Ω/km
PoE PoE (15,4W) IEEE 802.3af-2003 max. Channel PoE (15,4W) 70 m
Max. Channel-Link: Channel of Class FA / CAT 7A (@ 1000 MHz): 77m
Max. Permanent-Link: Permanent of Class FA / CAT 7A (@ 1000 MHz): 65m
Lengths & colours
Colour Length Matchcode item no.
0.30 CSE 0,3 NN 7A PUR 15586
0.50 CSE 0,5 NN 7A PUR 15587
1.00 CSE 1 NN 7A PUR 15588
1.50 CSE 1,5 NN 7A PUR 15589
2.00 CSE 2 NN 7A PUR 15590
3.00 CSE 3 NN 7A PUR 15591
5.00 CSE 5 NN 7A PUR 15592
10.00 CSE 10 NN 7A PUR 15593
15.00 CSE 15 NN 7A PUR 15594
20.00 CSE 20 NN 7A PUR 15595
